1035 Gallon White Plastic Elliptical Leg Tank

Save For Later Add To Compare

Share

Specifications

Part # ELN1035
Product Type Elliptical Leg Tank
Technical Drawing Protank ELN1035 Drawing
Specific Gravity 1.5
Weight (lbs) 284
Ship Freight Class 300
UV Inhibitors Yes
Color Natural White
Material Polyethylene
Translucent Yes
Gallon Indicators Yes
NSF Sticker Availability Ohio, Utah
Manufacturer Warranty 3 Year Warranty
Dimensions 89" Length x 79" Width x 54" Height
Capacity (Gallons) 1035
Liquid Access 1 Outlet - 1 Manway / Lid
Outlet / Drain 1 2" PP Female NPT Bulkhead Fitting
Manway / Lid 1 16" Threaded Vented Manway
Max Temp Allowed 130° F / 54° C
Bands Required Yes
Required Support Bands / Optional Full Length
Selected Product 796
